ABB
Regular price
R 166.24 ZAR
Regular price
R 302.26 ZAR
Sale price
R 166.24 ZAR
Unit price
/
per
SKU:
Part Number:2CDL210001R1060
Couldn't load pickup availability
PS1/60 Busbar
Specifications
| Technical |
|---|
| Standards: |
IEC/EN 60947-1 |
| Suitable For: |
S200F200DDA200 |
| Suitable for Product Class: |
1-pole devices (e.g. S201-SD201)Residual Current Circuit Breakers with Overcurrent Protection |
| Rated Operational Voltage: |
690 V AC/DCMaximum 690 V |
| Rated Short-time Withstand Current Low Voltage (Icw): |
25 kA |
| Rated Uninterrupted Current (Iu): |
63 A |
| Rated Frequency (f): |
50 / 60 HzDC |
| Pitch: |
44698.0 |
| Number of Poles: |
60 |
| Number of Phases: |
1 |
| Number of Mountable Devices: |
60 |
| Number of Terminals (Nterm): |
60 |
| Overvoltage Category: |
III |
| Accessory Type: |
Busbar |
| Connection Type: |
Pin |
| Housing Material: |
Light grey, RAL 7035 |
| Mounting Position: |
Any |
| RAL Number: |
RAL 7035 - Light Grey |
| Color: |
Grey |
| Rated Cross-Section: |
10 mm?ý |
| Environmental |
|---|
| Pollution Degree: |
2 |
| RoHS Status: |
Following EU Directive 2011/65/EU |
| Environmental Information: |
DIN EN 60068 |
| Dimensions |
|---|
| Width in Number of Modular Spacings: |
60 |
| Product Net Width: |
20 mm |
| Product Net Height: |
17 mm |
| Product Net Depth / Length: |
1050 mm |
| Product Net Weight: |
0.26 kg |
| Product Net Length: |
1050 mm |
| Container Information |
|---|
| Package Level 1 Units: |
20 piece |
| Package Level 1 Width: |
145 mm |
| Package Level 1 Height: |
140 mm |
| Package Level 1 Depth / Length: |
1100 mm |
| Package Level 1 Gross Weight: |
0.57 kg |
| Ordering |
|---|
| Minimum Order Quantity: |
1 piece |
| Customs Tariff Number: |
85369010 |
| E-Number (Finland): |
3259492 |
| E-Number (Sweden): |
2102522 |
| Country of Origin: |
Germany (DE) |
| Certificates and Declarations (Document Number) |
|---|
| Declaration of Conformity - CE: |
2CDK446006D0403 |
| Environmental Information: |
DIN EN 60068 |
| Instructions and Manuals: |
No document needed |
| RoHS Information: |
2CDK440009K0203 |
| Popular Downloads |
|---|
| Data Sheet, Technical Information: |
9AKK107991A8329 |
| Instructions and Manuals: |
No document needed |
| Classifications |
|---|
| ETIM 7: |
EC000215 - Phase busbar |
| ETIM 8: |
EC000215 - Phase busbar |
| EPLAN Catalog Tree: |
Electrical engineering / Protection devices / General |
| WEEE Category: |
4. Large Equipment (Any External Dimension More Than 50 cm) |
| WEEE B2C / B2B: |
Business To Consumer |
| CN8: |
8536 90 10 |
| UNSPSC: |
39121614 |
| eClass: |
V11.0 : 27371306 |
| Object Classification Code: |
W |
